16 cc/rev Hydraulic Gear Pump | Manufacturer & Global Supplier

Deslocamento:16 cc/rev

Pressão Nominal:20 MPa (2900 psi)

Pressão Máxima:25 MPa (3625 psi)

Velocidade Máxima:3000 rpm

Rotação:R: Direito (sentido horário)

Marca:BXHS

Tipo de produto:Bomba de engrenagem hidráulica

Série de produtos:Série CBHS-FL3 Bomba de engrenagem hidráulica

Tamanho da embalagem:20*20*20

Peso bruto:7.00 kg

Disponibilidade: Em estoque

1168 Visualizações estão procurando por este produto

16 cc/rev Hydraulic Gear Pump | Manufacturer & Global Supplier

16 cc/rev Hydraulic Gear Pump | Manufacturer & Global Supplier

16 cc/rev Hydraulic Gear Pump | Manufacturer & Global Supplier drawing image

This is a 16 cc/rev hydraulic gear pump with a displacement of 10 cc/rev, rated pressure of 20 MPa (2900 psi), and rated speed of 2000 r/min. It is available in left and right rotation configurations, features an internal gear pump design, and is constructed from aluminium. This pump is suitable for a wide range of applications, including material handling, construction, earth moving, agriculture, and industrial vehicles.

Série CBHS-FL3 Bomba de engrenagem hidráulica Parâmetros
Deslocamento 10 cc/rev, 4 cc/rev, 20 cc/rev, 16 cc/rev, 14 cc/rev, 6 cc/rev
Pressão Nominal 20 MPa (2900 psi)
Pressão Máxima 25 MPa (3625 psi)
Velocidade Nominal 2000 rpm
Velocidade Máxima 3000 rpm
Rotação L: Esquerdo (sentido anti-horário), R: Direito (sentido horário)
Material Alumínio
Estrutura Bomba de engrenagem externa
Versão da flange Flange oval A
Tipo de veio H: Chaveta retangular, X: Chaveta involuta, P: Chave Simples

This high-performance 16 cc/rev hydraulic gear pump is designed for demanding applications in material handling, construction, earth moving, agriculture, and industrial vehicles. It boasts a displacement of 10 cc/rev, a rated pressure of 20 MPa (2900 psi), and a rated speed of 2000 r/min, with a maximum speed of 3000 r/min. The pump is available in both left (counter-clockwise) and right (clockwise) rotation configurations, and features an internal gear pump design for reliability and efficiency. Constructed from robust aluminium, the pump is equipped with an A-Oval flange and a plain key shaft type. It belongs to the CBHS-FL3 series, known for its durability and performance. This pump is ideal for use in forklifts, telehandlers, skid steer loaders, compact wheel loaders, mini-excavators, midi-excavators, tractors and front-end loaders, harvesters, balers, and sprayers. As a global supplier, we offer manufacturing, OEM, ODM, private labeling, and customization services to meet specific customer requirements.
