20 cc/rev Hydraulic Gear Pump | Manufacturer & Global Supplier

Deslocamento:20 cc/rev

Pressão Nominal:20 MPa (2900 psi)

Pressão Máxima:25 MPa (3625 psi)

Velocidade Máxima:3000 rpm

Rotação:L: Esquerdo (sentido anti-horário)

Marca:BXHS

Tipo de produto:Bomba de engrenagem hidráulica

Série de produtos:Série CBHS-C20 Bomba de engrenagem hidráulica

Tamanho da embalagem:19*17*26

Peso bruto:8.50 kg

Disponibilidade: Em estoque

1263 Visualizações estão procurando por este produto

20 cc/rev Hydraulic Gear Pump | Manufacturer & Global Supplier

20 cc/rev Hydraulic Gear Pump | Manufacturer & Global Supplier

20 cc/rev Hydraulic Gear Pump | Manufacturer & Global Supplier drawing image

This 20 cc/rev Hydraulic Gear Pump is a high-performance, reliable, and durable pump designed for heavy-duty applications in construction, agriculture, and industrial vehicles. With a displacement of 100 cc/rev, rated pressure of 22 MPa (3190 psi), and max pressure of 25 MPa (3625 psi), this pump delivers exceptional power and efficiency.

Série CBHS-C20 Bomba de engrenagem hidráulica Parâmetros
Deslocamento 20 cc/rev
Pressão Nominal 20 MPa (2900 psi)
Pressão Máxima 25 MPa (3625 psi)
Velocidade Nominal 2500 rpm
Velocidade Máxima 3000 rpm
Rotação Bidirecional
Material Ferro Fundido
Estrutura Bomba de engrenagem externa
Versão da flange Orifícios de montagem ISO-4
Tipo de veio H: Chaveta retangular

This 20 cc/rev Hydraulic Gear Pump is a robust and reliable solution for a wide range of applications in the construction, agriculture, and industrial vehicle industries. Featuring a displacement of 100 cc/rev, rated pressure of 22 MPa (3190 psi), and maximum pressure of 25 MPa (3625 psi), this pump provides exceptional power and efficiency. Its bidirectional rotation and external gear pump design ensure smooth and consistent performance. Constructed with cast iron for superior durability, the pump is designed for long-term, heavy-duty operation. Equipped with ISO-4 mounting holes and a rectangle spline shaft, the pump offers easy integration into various systems. It is particularly well-suited for use in forklifts, telehandlers, mini-excavators, skid steer loaders, compact wheel loaders, wheel loaders, tractors, front-end loaders, harvesters, and balers. Choose this high-performance hydraulic gear pump for unparalleled power, reliability, and durability in your demanding applications.
