BF110M Hydraulic Gear Pump: Robust 20 MPa (2900 psi) Design

Deslocamento:110 cc/rev

Pressão Nominal:20 MPa (2900 psi)

Pressão Máxima:25 MPa (3625 psi)

Velocidade Máxima:2500 rpm

Rotação:Bidirecional

Fornecedor:BXHS

Tipo de produto:Bomba de engrenagem hidráulica

Série de produtos:Série BF Bomba de engrenagem hidráulica

Packagingsize:34*20*17

Grossweight:24.90 kg

Disponibilidade: Em estoque

344 Visualizações estão procurando por este produto

BF110M Hydraulic Gear Pump: Robust 20 MPa (2900 psi) Design

BF110M Hydraulic Gear Pump: Robust 20 MPa (2900 psi) Design

BF110M Hydraulic Gear Pump: Robust 20 MPa (2900 psi) Design drawing image

Discover the BF110M Hydraulic Gear Pump, engineered for robust performance in demanding applications. With a 110 cc/rev displacement and a rated pressure of 20 MPa, this cast iron pump offers reliable, bidirectional operation. It is suitable for a range of industries including material handling, construction, agriculture, and industrial vehicles, providing a dependable solution for diverse hydraulic system needs.

Série BF Bomba de engrenagem hidráulica Parâmetros
Deslocamento 63 cc/rev, 80 cc/rev, 110 cc/rev, 43 cc/rev
Pressão Nominal 20 MPa (2900 psi), 25 MPa (3625 psi)
Velocidade Nominal 2000 rpm
Estrutura Bomba de engrenagem externa, Bomba de engrenagem interna
Material Ferro Fundido
Tipo de veio H: Chaveta retangular, P: Chave Simples
Versão da flange Flange oval A, Orifícios de montagem UNI-3
Pressão Máxima 25 MPa (3625 psi)
Rotação Bidirecional
Velocidade Máxima 2500 rpm

As a dedicated manufacturer and factory supplier of hydraulic products, we present the BF110M Hydraulic Gear Pump, a robust solution for a wide array of global applications. This **high-pressure gear pump** features a 110 cc/rev displacement and a rated pressure of 20 MPa (2900 psi), designed for consistent performance even under challenging conditions. Constructed from durable **cast iron**, the BF110M pump offers reliable, **bidirectional** operation, making it versatile for various hydraulic systems.

Our **BF Series pump** is highly adaptable, available with **UNI-3 mounting holes** or **A-oval flanges** and **rectangle spline** or **plain key shaft types**, ensuring compatibility with diverse machinery. It is an ideal **industrial hydraulic pump** for sectors such as **material handling**, **construction and earth moving**, **agriculture**, and general **industrial vehicles**. Specific applications include **telehandlers**, **forklifts**, **midi-excavators**, **skid steer loaders**, **wheel loaders**, **backhoe loaders**, **tractors and front-end loaders**, **harvesters**, **aerial platforms**, and **dumpers**.

We offer flexible partnership opportunities including **OEM hydraulic** manufacturing, **ODM services**, **private label** options, and **custom gear pump** solutions tailored to your specific requirements. We specialize in **factory wholesale** and large-scale supply. We are actively seeking long-term collaborations with **distributors**, **wholesalers**, **agents**, and **traders** globally to expand the reach of our quality hydraulic products. Partner with us for reliable **factory direct supply** and expertise in hydraulic pump manufacturing.
