BZZ1-E100B Hydraulic Steering Unit: OEM & ODM Services Available

Deslocamento:100 ml/r

Fluxo Nominal:7,5 L/min

Marca:BXHS

Tipo de produto:Unidade de Direção

Série de produtos:Série BZZ1 Unidade de Direção

Tamanho da embalagem:12*11*15

Peso bruto:6.30 kg

Disponibilidade: Em estoque

512 Visualizações estão procurando por este produto

BZZ1-E100B Hydraulic Steering Unit: OEM & ODM Services Available

BZZ1-E100B Hydraulic Steering Unit: OEM & ODM Services Available

BZZ1-E100B Hydraulic Steering Unit: OEM & ODM Services Available drawing image

BZZ1-E100B Hydraulic Steering Unit (100 ml/r displacement) for material handling, construction, and industrial vehicles. OEM, ODM, custom design, and wholesale services available. Contact us for distribution opportunities.

Série BZZ1 Unidade de Direção Parâmetros
Deslocamento 50 ml/r, 63 ml/r, 100 ml/r, 80 ml/r, 125 ml/r, 160 ml/r, 200 ml/r, 250 ml/r, 280 ml/r, 315 ml/r, 400 ml/r, 500 ml/r, 630 ml/r, 800 ml/r, 1000 ml/r
Bloco de Válvulas Personalizável
Material Ferro Fundido
Fluxo Nominal 5 L/min, 6 L/min, 4 L/min, 7,5 L/min, 9,5 L/min, 12 L/min, 15 L/min, 19 L/min, 21 L/min, 24 L/min, 30 L/min, 38 L/min, 48 L/min, 60 L/min, 75 L/min
Pressão máxima de retorno contínua 2,5 Mpa
Pressão máxima de entrada 16 Mpa

The BZZ1-E100B Hydraulic Steering Unit is a high-performance, reliable solution for a wide range of applications, including forklifts, skid steer loaders, compact wheel loaders, telehandlers, mini-excavators, tractors, and front-end loaders. With a displacement of 100 ml/r, a maximum input pressure of 16 MPa, and a rated flow of 7.5 L/min, this cast iron unit offers exceptional durability and performance. Its customizable valve block ensures adaptability to specific customer requirements.

**Key Features:**
* Displacement: 100 ml/r
* Max. Input Pressure: 16 MPa
* Max. Cont. Back Pressure: 2.5 MPa
* Rated Flow: 7.5 L/min
* Material: Cast Iron
* Customizable Valve Block
* Applications: Material Handling, Construction & Earth Moving, Industrial Vehicles

**We Offer:**
* **OEM Services:** Manufacture to your specifications.
* **ODM Services:** Design and manufacture according to your requirements.
* **Private Labeling:** Brand your own hydraulic steering unit.
* **Custom Design:** Tailored solutions to meet your unique needs.
* **Wholesale Pricing:** Competitive pricing for bulk orders.

**We are seeking:**
* Distributors
* Wholesalers
* Agents
* Trading Companies

As a leading manufacturer and factory supplier, we provide high-quality hydraulic steering units at factory-direct wholesale prices. Partner with us to expand your product offerings and tap into growing global markets. Contact us today to discuss your specific needs and explore our OEM, ODM, and private labeling opportunities.
