Direct from Manufacturer: Q45 5 Spool Monoblock Hydraulic Control Valve

Método de Controle:Eletroímã de tração-compressão (push-pull)

Carrétel:5 Carreteis

Fluxo Nominal:45 L/min (11,8 US gpm)

Pressão Máxima:315 bar (4600 psi)

Porta de Entrada:G1/2

Porta de Saída:G1/2

Tamanho da Porta:G1/2

Marca:BXHS

Tipo de produto:Válvula Direcional Monobloco

Série de produtos:Série Q45 Válvula Direcional Monobloco

Tamanho da embalagem:30*35*17

Peso bruto:19.00 kg

Disponibilidade: Em estoque

360 Visualizações estão procurando por este produto

Direct from Manufacturer: Q45 5 Spool Monoblock Hydraulic Control Valve

Direct from Manufacturer: Q45 5 Spool Monoblock Hydraulic Control Valve

Direct from Manufacturer: Q45 5 Spool Monoblock Hydraulic Control Valve drawing image

As a direct manufacturer, we offer the Q45 5-spool monoblock hydraulic control valve, featuring both solenoid and manual control. Designed for a 45 L/min flow and 315 bar pressure, this versatile valve is suitable for a wide range of applications including material handling, construction, agriculture, and industrial vehicles, ensuring reliable performance across various demanding machinery.

Série Q45 Válvula Direcional Monobloco Parâmetros
Método de Controle Manual, Pneumático, Eletropneumático, Eletrohidráulico, Solenoide, Joystick, Solenóide e Manual, Eletroímã manual e de tração-compressão (push-pull), Eletroímã de tração-compressão (push-pull)
Carrétel 1 Carretel, 2 Carreteis, 3 Carreteis, 4 Carreteis, 5 Carreteis, 6 Carreteis, 7 Carreteis
Intervalo de temperatura ambiente -20°C a +80°C (-4°F a +176°F)
Tipo de estrutura Válvula monobloco
Secção 1 secção, 2 secções, 3 secções, 4 secções, 5 secções, 6 secções, 7 secções
Intervalo de viscosidade operacional 15 - 75 mm²/s (15 cSt a 75 cSt)
Fluxo Nominal 45 L/min (11,8 US gpm)
Pressão Máxima 315 bar (4600 psi)
Porta de Entrada G1/2
Porta de Saída G1/2
Tamanho da Porta G1/2

Discover the Q45 5-spool monoblock hydraulic control valve, expertly engineered for robust performance in diverse industrial applications. This high-quality valve offers a rated flow of 45 L/min (11.8 US gpm) and a maximum pressure of 315 bar (4600 psi), controlled by both solenoid and manual methods for operational flexibility. It is ideally suited for material handling, construction and earth-moving machinery, agricultural equipment, and industrial vehicles, including telehandlers, forklifts, aerial platforms, excavators (midi and mini), skid steer loaders, backhoe loaders, tractors, front-end loaders, harvesters, and dumpers.

As a dedicated hydraulic product manufacturer, we provide comprehensive solutions to meet global market demands. Our services include:
* **Manufacturing:** Leveraging our state-of-the-art facilities for consistent quality production.
* **OEM (Original Equipment Manufacturing):** Producing components and systems under your brand specifications.
* **ODM (Original Design Manufacturing):** Offering design and manufacturing expertise for custom solutions.
* **Private Label:** Custom branding options for our high-performance valves.
* **Customization:** Tailoring products to your unique application requirements.
* **Wholesale:** Supplying bulk orders directly from our factory.

We are actively seeking strong, long-term partnerships with **distributors, wholesalers, agents, and traders** worldwide. Benefit from direct **factory supply** and **factory wholesale pricing**, ensuring competitive advantages and reliable stock. Partner with us, a trusted **manufacturer**, for your hydraulic component needs, and access quality products and flexible service options.
