Exclusive Factory Pricing: P80-U78-1OT Hydraulic Directional Valve Wholesale

Método de Controle:Manual

Carrétel:1 Carretel

Fluxo Nominal:80 L/min (21,2 US gpm)

Pressão Máxima:250 bar (3600 psi)

Porta de Entrada:SAE 10

Porta de Saída:SAE 10

Tamanho da Porta:SAE 10

Marca:BXHS

Tipo de produto:Válvula Direcional Monobloco

Série de produtos:Série P80 Válvula Direcional Monobloco

Tamanho da embalagem:25.1*15*11

Peso bruto:5.00 kg

Disponibilidade: Em estoque

959 Visualizações estão procurando por este produto

Exclusive Factory Pricing: P80-U78-1OT Hydraulic Directional Valve Wholesale

Exclusive Factory Pricing: P80-U78-1OT Hydraulic Directional Valve Wholesale

Exclusive Factory Pricing: P80-U78-1OT Hydraulic Directional Valve Wholesale drawing image

Introducing our exclusive factory-priced P80-U78-1OT Hydraulic Directional Valve, the ultimate solution for your hydraulic system needs. Manufactured with the highest standards of precision and reliability, this valve features a robust monoblock design, manual control, and exceptional performance capabilities.

Série P80 Válvula Direcional Monobloco Parâmetros
Método de Controle Manual, Pneumático, Eletropneumático, Eletrohidráulico, Solenoide, Hidráulico, Hidráulico e Manual, Cabo, Joystick, Manual e Joystick
Carrétel 1 Carretel, 2 Carreteis, 3 Carreteis, 4 Carreteis, 5 Carreteis, 6 Carreteis, 7 Carreteis
Intervalo de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estrutura Válvula monobloco
Secção 1 secção, 2 secções, 3 secções, 4 secções, 5 secções, 6 secções, 7 secções
Intervalo de viscosidade operacional 15 - 75 mm²/s (15 cSt a 75 cSt)
Fluxo Nominal 80 L/min (21,2 US gpm)
Pressão Máxima 315 bar (4600 psi)
Porta de Entrada G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Porta de Saída G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Tamanho da Porta G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

Our P80-U78-1OT Hydraulic Directional Valve is meticulously engineered to deliver exceptional performance in demanding applications. With a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 250 bar (3600 psi), it ensures efficient and reliable operation in a wide range of hydraulic systems. The valve's operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and ambient temperature range of -40°C to +80°C (-40°F to +176°F) make it suitable for diverse operating conditions.

As a leading hydraulic products manufacturer, we offer exclusive factory pricing on our P80-U78-1OT Hydraulic Directional Valve. By sourcing directly from our state-of-the-art production facilities, you can enjoy significant cost savings while ensuring the highest quality standards. Our commitment to excellence extends beyond manufacturing; we also provide comprehensive support, including technical assistance and after-sales services, to ensure your complete satisfaction.
