Método de Controle:Solenoide

Carrétel:5 Carreteis

Fluxo Nominal:80 L/min (21,2 US gpm)

Pressão Máxima:200 bar (2900 psi)

Porta de Entrada:G1/2

Porta de Saída:G3/4

Tamanho da Porta:G1/2

Marca:BXHS

Tipo de produto:Válvula Direcional Monobloco

Série de produtos:Série P80 Válvula Direcional Monobloco

Tamanho da embalagem:33*44*11

Peso bruto:19.50 kg

Disponibilidade: Em estoque

1163 Visualizações estão procurando por este produto

Fluid Power

Fluid Power

Fluid Power drawing image

This hydraulic spool control valve is designed for electric remote control of fluid power systems in material handling, construction, agriculture, and industrial vehicles. Featuring a monoblock structure, 5 sections, and a rated flow of 80 L/min, it operates at pressures up to 250 bar.

Série P80 Válvula Direcional Monobloco Parâmetros
Método de Controle Manual, Pneumático, Eletropneumático, Eletrohidráulico, Solenoide, Hidráulico, Hidráulico e Manual, Cabo, Joystick, Manual e Joystick
Carrétel 1 Carretel, 2 Carreteis, 3 Carreteis, 4 Carreteis, 5 Carreteis, 6 Carreteis, 7 Carreteis
Intervalo de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estrutura Válvula monobloco
Secção 1 secção, 2 secções, 3 secções, 4 secções, 5 secções, 6 secções, 7 secções
Intervalo de viscosidade operacional 15 - 75 mm²/s (15 cSt a 75 cSt)
Fluxo Nominal 80 L/min (21,2 US gpm)
Pressão Máxima 315 bar (4600 psi)
Porta de Entrada G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Porta de Saída G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Tamanho da Porta G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

This high-performance hydraulic spool valve is engineered for demanding applications in material handling, construction, and industrial vehicles. It features an electric remote control method with a solenoid for precise actuation. The monoblock structure provides durability and reliability, while the 5-section design allows for versatile control configurations. The valve boasts a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 250 bar (3600 psi). Its wide operating viscosity range (15 - 75 mm²/s) ensures consistent performance across various operating conditions. The valve is designed for ambient temperatures ranging from -40°C to +80°C (-40°F to +176°F), making it suitable for diverse environments. This valve is ideal for a wide range of applications, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders.
