High-Quality P80-G34-G12-AT-3OT Directional Valve for Hydraulic Systems

Método de Controle:Manual

Carrétel:4 Carreteis

Fluxo Nominal:80 L/min (21,2 US gpm)

Pressão Máxima:250 bar (3600 psi)

Porta de Entrada:G1/2

Porta de Saída:G3/4

Tamanho da Porta:G1/2

Marca:BXHS

Tipo de produto:Válvula Direcional Monobloco

Série de produtos:Série P80 Válvula Direcional Monobloco

Tamanho da embalagem:26*27*11

Peso bruto:13.40 kg

Disponibilidade: Em estoque

1416 Visualizações estão procurando por este produto

High-Quality P80-G34-G12-AT-3OT Directional Valve for Hydraulic Systems

High-Quality P80-G34-G12-AT-3OT Directional Valve for Hydraulic Systems

High-Quality P80-G34-G12-AT-3OT Directional Valve for Hydraulic Systems drawing image

The P80-G34-G12-AT-3OT is a high-quality 4-section monoblock directional valve designed for hydraulic systems. It features a joystick control method, a rated flow of 80 L/min (21.2 US gpm), and a maximum pressure of 250 bar (3600 psi). This versatile valve is suitable for various applications, including material handling, construction, agriculture, and industrial vehicles.

Série P80 Válvula Direcional Monobloco Parâmetros
Método de Controle Manual, Pneumático, Eletropneumático, Eletrohidráulico, Solenoide, Hidráulico, Hidráulico e Manual, Cabo, Joystick, Manual e Joystick
Carrétel 1 Carretel, 2 Carreteis, 3 Carreteis, 4 Carreteis, 5 Carreteis, 6 Carreteis, 7 Carreteis
Intervalo de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estrutura Válvula monobloco
Secção 1 secção, 2 secções, 3 secções, 4 secções, 5 secções, 6 secções, 7 secções
Intervalo de viscosidade operacional 15 - 75 mm²/s (15 cSt a 75 cSt)
Fluxo Nominal 80 L/min (21,2 US gpm)
Pressão Máxima 315 bar (4600 psi)
Porta de Entrada G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Porta de Saída G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Tamanho da Porta G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80-G34-G12-AT-3OT joystick hydraulic valve is a robust and reliable solution for demanding hydraulic systems. Its 4-section monoblock construction ensures high performance and durability. With a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure rating of 250 bar (3600 psi), this valve is capable of handling heavy-duty applications. The valve is designed to operate within an ambient temperature range of -40°C to +80°C (-40°F to +176°F) and a viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt). Its 4-spool configuration provides precise control over hydraulic functions. The P80-G34-G12-AT-3OT is ideal for a wide range of applications, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, and skid steer loaders. Its high-quality construction, robust performance, and versatility make it an excellent choice for manufacturers and users in various industries.
