Hydraulic Control Valve, 4-Spool, Manual Operation - P80-U78-4OT

Método de Controle:Manual

Carrétel:4 Carreteis

Fluxo Nominal:80 L/min (21,2 US gpm)

Pressão Máxima:250 bar (3600 psi)

Porta de Entrada:SAE 10

Porta de Saída:SAE 10

Tamanho da Porta:SAE 10

Marca:BXHS

Tipo de produto:Válvula Direcional Monobloco

Série de produtos:Série P80 Válvula Direcional Monobloco

Tamanho da embalagem:26*27*11

Peso bruto:13.40 kg

Disponibilidade: Em estoque

1048 Visualizações estão procurando por este produto

Hydraulic Control Valve, 4-Spool, Manual Operation - P80-U78-4OT

Hydraulic Control Valve, 4-Spool, Manual Operation - P80-U78-4OT

Hydraulic Control Valve, 4-Spool, Manual Operation - P80-U78-4OT drawing image

The Hydro Control P80-U78-4OT is a 4-spool, manually operated hydraulic control valve designed for heavy-duty applications in material handling, construction, and agriculture. With a rated flow of 80 L/min and a maximum pressure of 250 bar, it is suitable for use in a wide range of industrial vehicles including telehandlers, forklifts, cranes, and excavators.

Série P80 Válvula Direcional Monobloco Parâmetros
Método de Controle Manual, Pneumático, Eletropneumático, Eletrohidráulico, Solenoide, Hidráulico, Hidráulico e Manual, Cabo, Joystick, Manual e Joystick
Carrétel 1 Carretel, 2 Carreteis, 3 Carreteis, 4 Carreteis, 5 Carreteis, 6 Carreteis, 7 Carreteis
Intervalo de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estrutura Válvula monobloco
Secção 1 secção, 2 secções, 3 secções, 4 secções, 5 secções, 6 secções, 7 secções
Intervalo de viscosidade operacional 15 - 75 mm²/s (15 cSt a 75 cSt)
Fluxo Nominal 80 L/min (21,2 US gpm)
Pressão Máxima 315 bar (4600 psi)
Porta de Entrada G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Porta de Saída G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Tamanho da Porta G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The Hydro Control P80-U78-4OT is a robust and reliable hydraulic control valve designed for demanding applications. Its 4-spool, monoblock construction provides a compact and efficient design, while its manual operation allows for precise control of hydraulic functions. The valve is rated for a flow of 80 L/min and a maximum pressure of 250 bar, making it suitable for use in a wide range of industrial vehicles, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, and wheel loaders. The valve's operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) ensures optimal performance in various operating conditions. It can withstand ambient temperatures ranging from -40°C to +80°C (-40°F to +176°F), making it suitable for use in a variety of climates. The P80-U78-4OT is a reliable and durable solution for controlling hydraulic systems in a variety of demanding applications.
