Hydraulic Product Manufacturer: P120-G1 Monoblock Valve

Método de Controle:Manual

Carrétel:1 Carretel

Fluxo Nominal:120 L/min (31.7 US gpm)

Pressão Máxima:250 bar (3600 psi)

Porta de Entrada:G1

Porta de Saída:G1

Tamanho da Porta:G1

Marca:BXHS

Tipo de produto:Válvula Direcional Monobloco

Série de produtos:Série P120 Válvula Direcional Monobloco

Tamanho da embalagem:19*35*16

Peso bruto:13.60 kg

Disponibilidade: Em estoque

976 Visualizações estão procurando por este produto

Hydraulic Product Manufacturer: P120-G1 Monoblock Valve

Hydraulic Product Manufacturer: P120-G1 Monoblock Valve

Hydraulic Product Manufacturer: P120-G1 Monoblock Valve drawing image

The P120-G1 Monoblock Valve is a high-performance, adjustable hydraulic flow divider valve designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles. This manual control valve features a compact, robust design with a rated flow of 120 L/min (31.7 US gpm) and a maximum pressure of 250 bar (3600 psi).

Série P120 Válvula Direcional Monobloco Parâmetros
Método de Controle Manual, Cabo, Joystick, Manual e Joystick
Carrétel 1 Carretel, 2 Carreteis, 3 Carreteis, 4 Carreteis
Fluxo Nominal 120 L/min (31.7 US gpm)
Pressão Máxima 250 bar (3600 psi)
Porta de Entrada G3/4, G1, M27×2.0, SAE 14, SAE 16, 3/4 NPT, 1 NPT, M36×2
Porta de Saída G1, SAE 16, 1 NPT, M36×2
Tamanho da Porta G3/4, G1, M27×2.0, SAE 14, SAE 16, 1 NPT, M36×2
Secção 1 secção, 2 secções, 3 secções, 4 secções
Tipo de estrutura Válvula monobloco
Intervalo de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Intervalo de viscosidade operacional 15 - 75 mm²/s (15 cSt a 75 cSt)

The P120-G1 Monoblock Valve is a reliable and efficient solution for controlling hydraulic flow in demanding applications. Its robust monoblock construction ensures durability and long service life. This adjustable flow divider valve allows for precise control of hydraulic fluid flow, enabling optimized performance in various equipment such as telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, excavators, skid steer loaders, and compact wheel loaders. The valve operates at a flow rate of 120 L/min (31.7 US gpm) and a maximum pressure of 250 bar (3600 psi), making it suitable for high-demand applications. The manual control method provides simple and direct operation. The P120-G1 Monoblock Valve is a versatile and reliable solution for a wide range of applications in the construction, agriculture, and industrial vehicle sectors.
