Hydraulic Valve Manufacturer | P40-G12-1OT Directional Valve

Método de Controle:Manual

Carrétel:1 Carretel

Fluxo Nominal:40 L/min (10,5 US gpm)

Pressão Máxima:250 bar (3600 psi)

Porta de Entrada:G1/2

Porta de Saída:G1/2

Tamanho da Porta:G1/2

Marca:BXHS

Tipo de produto:Válvula Direcional Monobloco

Série de produtos:Série P40 Válvula Direcional Monobloco

Tamanho da embalagem:23*16*11

Peso bruto:3.00 kg

Disponibilidade: Em estoque

1049 Visualizações estão procurando por este produto

Hydraulic Valve Manufacturer | P40-G12-1OT Directional Valve

Hydraulic Valve Manufacturer | P40-G12-1OT Directional Valve

Hydraulic Valve Manufacturer | P40-G12-1OT Directional Valve drawing image

The P40-G12-1OT Directional Valve is a high-performance, manual control, monoblock hydraulic valve designed for various applications in construction, agriculture, and industrial vehicles. It features a rated flow of 40 L/min and a maximum pressure of 250 bar, making it ideal for telehandlers, forklifts, cranes, stackers, and more.

Série P40 Válvula Direcional Monobloco Parâmetros
Método de Controle Manual, Pneumático, Eletropneumático, Eletrohidráulico, Solenoide, Hidráulico, Hidráulico e Manual, Cabo, Joystick, Solenoide e Joystick, Manual e Joystick, Solenoide e cabo
Carrétel 1 Carretel, 2 Carreteis, 3 Carreteis, 4 Carreteis, 5 Carreteis, 6 Carreteis, 7 Carreteis
Intervalo de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estrutura Válvula monobloco
Secção 1 secção, 2 secções, 3 secções, 4 secções, 5 secções, 6 secções, 7 secções
Intervalo de viscosidade operacional 15 - 75 mm²/s (15 cSt a 75 cSt)
Fluxo Nominal 40 L/min (10,5 US gpm)
Pressão Máxima 250 bar (3600 psi)
Porta de Entrada G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Porta de Saída G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Tamanho da Porta G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-G12-1OT Directional Valve is a robust and reliable hydraulic valve designed for demanding applications. It features a single spool and a single section with manual control, providing precise flow control and directional switching. Its monoblock construction ensures high strength and durability. With a rated flow of 40 L/min and a maximum pressure of 250 bar, this valve can handle a wide range of hydraulic systems. Its operating viscosity range of 15 - 75 mm²/s allows for use in various fluid conditions. The P40-G12-1OT is designed for a wide range of applications, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. Its rugged construction and wide operating temperature range of -40°C to +80°C make it suitable for use in challenging environments.
