Industrial Hydraulic Gear Pump - 40 cc/rev - Manufacturer & Supplier

Deslocamento:20 cc/rev

Pressão Nominal:20 MPa (2900 psi)

Pressão Máxima:25 MPa (3625 psi)

Velocidade Máxima:2500 rpm

Rotação:L: Esquerdo (sentido anti-horário)

Marca:BXHS

Tipo de produto:Bomba de engrenagem hidráulica

Série de produtos:Série CBHS-F4 Bomba de engrenagem hidráulica

Tamanho da embalagem:22*36*22

Peso bruto:7.50 kg

Disponibilidade: Em estoque

1230 Visualizações estão procurando por este produto

Industrial Hydraulic Gear Pump - 40 cc/rev - Manufacturer & Supplier

Industrial Hydraulic Gear Pump - 40 cc/rev - Manufacturer & Supplier

Industrial Hydraulic Gear Pump - 40 cc/rev - Manufacturer & Supplier drawing image

This Industrial Hydraulic Gear Pump is a high-performance, durable and reliable pump designed for various construction, agricultural, and industrial applications. Available in different displacement sizes and pressure ratings, it caters to diverse needs and equipment types.

Série CBHS-F4 Bomba de engrenagem hidráulica Parâmetros
Deslocamento 40 cc/rev, 25 cc/rev, 20 cc/rev
Pressão Nominal 20 MPa (2900 psi), 25 MPa (3625 psi)
Pressão Máxima 25 MPa (3625 psi)
Velocidade Nominal 2000 rpm
Velocidade Máxima 2500 rpm
Rotação L: Esquerdo (sentido anti-horário), R: Direito (sentido horário)
Material Ferro Fundido, Ferro fundido de alumínio, Alumínio
Estrutura Tipo de prato de came
Versão da flange Flange oval A, Flange quadrado B, Orifícios de montagem ISO-4, Orifícios de montagem UNI-3, Flange SAE
Tipo de veio H: Chaveta retangular, X: Chaveta involuta, P: Chave Simples

This Industrial Hydraulic Gear Pump is a reliable and durable solution for a wide range of applications in construction, agriculture, and industrial vehicles. It offers displacement options ranging from 32 cc/rev to 80 cc/rev and pressure ratings up to 3625 psi (25 MPa). The pump features an external gear design with a cam plate type structure and is available with both A-oval and B-square flange versions. It also features a rectangle spline shaft for easy installation. The pump is suitable for various equipment such as forklifts, telehandlers, mini-excavators, midi-excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, tractors, front-end loaders, and harvesters. Our company offers manufacturing, OEM, ODM, and customization services to meet the specific needs of our clients. We are actively seeking distributors, wholesalers, agents, and traders to expand our global reach and offer our high-quality hydraulic gear pumps to a wider market.
