Log Splitter Hydraulic Valve | P81 Model | Factory Direct & Customizable

Método de Controle:Manual

Carrétel:1 Carretel

Fluxo Nominal:80 L/min (21,2 US gpm)

Pressão Máxima:Pressão máxima

Porta de Entrada:G1/2

Porta de Saída:G3/4

Tamanho da Porta:G3/4

Marca:BXHS

Tipo de produto:Válvula para Rachador de Lenha

Série de produtos:Série P81 Válvula para Rachador de Lenha

Tamanho da embalagem:27*16*12

Peso bruto:4.80 kg

Disponibilidade: Em estoque

2152 Visualizações estão procurando por este produto

Log Splitter Hydraulic Valve | P81 Model | Factory Direct & Customizable

Log Splitter Hydraulic Valve | P81 Model | Factory Direct & Customizable

Log Splitter Hydraulic Valve | P81 Model | Factory Direct & Customizable drawing image

The P81 hydraulic valve is a high-performance, heavy-duty valve designed for use in tractor-powered log splitters. It features a manual control method, 1 section monoblock construction, 80 L/min flow rate, and 250 bar maximum pressure. This durable valve is perfect for industrial applications and offers customizable options to meet your specific needs.

Série P81 Válvula para Rachador de Lenha Parâmetros
Método de Controle Manual
Carrétel 1 Carretel
Intervalo de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estrutura Válvula monobloco
Secção 1 secção
Intervalo de viscosidade operacional 15 - 75 mm²/s (15 cSt a 75 cSt)
Fluxo Nominal 80 L/min (21,2 US gpm), 95 L/min (25,1 US gpm)
Pressão Máxima Pressão máxima
Porta de Entrada G1/2
Porta de Saída G1/2
Tamanho da Porta G3/4

The P81 model is a robust tractor joy stick log splitter hydraulic valve, ideal for industrial vehicles. This monoblock valve boasts a 1 section design and offers a rated flow of 80 L/min (21.2 US gpm) with a maximum pressure of 250 bar (3600 psi). It operates within a wide viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and can withstand ambient temperatures from -40°C to +80°C (-40°F to +176°F). The valve features a single spool with a kick-out setting pressure of 70~140bar (1015-2030psi). We offer this valve for manufacturing, OEM, private label, and custom orders, allowing you to tailor it to your specific requirements. We are also actively seeking distributors, wholesalers, agents, and traders worldwide. Contact us today to discuss your needs and explore the possibilities of this high-quality, customizable hydraulic valve.
