Manual and Joystick Valve | P40-2OT Series | Key Features & Applications

Método de Controle:Manual e Joystick

Carrétel:2 Carreteis

Fluxo Nominal:40 L/min (10,5 US gpm)

Pressão Máxima:250 bar (3600 psi)

Porta de Entrada:G1/2

Porta de Saída:G1/2

Tamanho da Porta:G3/8

Marca:BXHS

Tipo de produto:Válvula Direcional Monobloco

Série de produtos:Série P40 Válvula Direcional Monobloco

Tamanho da embalagem:23*18*13

Peso bruto:5.20 kg

Disponibilidade: Em estoque

1197 Visualizações estão procurando por este produto

Manual and Joystick Valve | P40-2OT Series | Key Features & Applications

Manual and Joystick Valve | P40-2OT Series | Key Features & Applications

Manual and Joystick Valve | P40-2OT Series | Key Features & Applications drawing image

The Bxhs P40-2OT Series Hydraulic Manual and Joystick Valve is a 2-section monoblock valve with a rated flow of 40 L/min and a maximum pressure of 250 bar. Ideal for various applications in material handling, construction, and industrial vehicles.

Série P40 Válvula Direcional Monobloco Parâmetros
Método de Controle Manual, Pneumático, Eletropneumático, Eletrohidráulico, Solenoide, Hidráulico, Hidráulico e Manual, Cabo, Joystick, Solenoide e Joystick, Manual e Joystick, Solenoide e cabo
Carrétel 1 Carretel, 2 Carreteis, 3 Carreteis, 4 Carreteis, 5 Carreteis, 6 Carreteis, 7 Carreteis
Intervalo de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estrutura Válvula monobloco
Secção 1 secção, 2 secções, 3 secções, 4 secções, 5 secções, 6 secções, 7 secções
Intervalo de viscosidade operacional 15 - 75 mm²/s (15 cSt a 75 cSt)
Fluxo Nominal 40 L/min (10,5 US gpm)
Pressão Máxima 250 bar (3600 psi)
Porta de Entrada G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Porta de Saída G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Tamanho da Porta G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The Bxhs P40-2OT Series is a robust and versatile hydraulic valve designed for demanding applications in material handling, construction, and industrial vehicles. This 2-section monoblock valve features a manual and joystick control method, offering precise and reliable control. It boasts a rated flow of 40 L/min and a maximum pressure of 250 bar, making it suitable for a wide range of equipment. The valve operates within a viscosity range of 15 to 75 mm²/s and can withstand ambient temperatures from -40°C to +80°C. With its 2-spool design, the P40-2OT Series provides flexibility and adaptability, ensuring compatibility with various machine types. This valve is specifically designed for applications in telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders.
