P120 Directional Valve: Quality, Performance, Reliability

Método de Controle:Manual

Carrétel:2 Carreteis

Fluxo Nominal:120 L/min (31.7 US gpm)

Pressão Máxima:250 bar (3600 psi)

Porta de Entrada:G1

Porta de Saída:G1

Tamanho da Porta:G1

Marca:BXHS

Tipo de produto:Válvula Direcional Monobloco

Série de produtos:Série P120 Válvula Direcional Monobloco

Tamanho da embalagem:30*39*17

Peso bruto:19.00 kg

Disponibilidade: Em estoque

1630 Visualizações estão procurando por este produto

P120 Directional Valve: Quality, Performance, Reliability

P120 Directional Valve: Quality, Performance, Reliability

P120 Directional Valve: Quality, Performance, Reliability drawing image

The P120 Series 5/2 Directional Control Valve is a reliable and high-performance hydraulic valve designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles. This manual control valve features a robust monoblock construction, rated flow of 120 L/min, and a maximum pressure of 250 bar, making it ideal for demanding operating conditions.

Série P120 Válvula Direcional Monobloco Parâmetros
Método de Controle Manual, Cabo, Joystick, Manual e Joystick
Carrétel 1 Carretel, 2 Carreteis, 3 Carreteis, 4 Carreteis
Fluxo Nominal 120 L/min (31.7 US gpm)
Pressão Máxima 250 bar (3600 psi)
Porta de Entrada G3/4, G1, M27×2.0, SAE 14, SAE 16, 3/4 NPT, 1 NPT, M36×2
Porta de Saída G1, SAE 16, 1 NPT, M36×2
Tamanho da Porta G3/4, G1, M27×2.0, SAE 14, SAE 16, 1 NPT, M36×2
Secção 1 secção, 2 secções, 3 secções, 4 secções
Tipo de estrutura Válvula monobloco
Intervalo de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Intervalo de viscosidade operacional 15 - 75 mm²/s (15 cSt a 75 cSt)

The P120 Series 5/2 Directional Control Valve is a high-quality hydraulic valve designed for demanding applications in material handling, construction, agriculture, and industrial vehicles. This manual control valve features a robust monoblock construction, providing exceptional durability and reliability. With a rated flow of 120 L/min and a maximum pressure of 250 bar, this valve can handle high flow rates and pressures. The valve operates smoothly across a wide viscosity range (15-75 mm²/s) and can withstand temperatures from -40°C to +80°C. Its 2-section design and 2-spool configuration allow for precise control of hydraulic circuits. The valve is compatible with a wide range of applications, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, excavators, skid steer loaders, and compact wheel loaders.
