P40-G12-1OT Hydraulic Directional Valve | Manufacturer & Global Supplier

Método de Controle:Manual

Carrétel:1 Carretel

Fluxo Nominal:40 L/min (10,5 US gpm)

Pressão Máxima:250 bar (3600 psi)

Porta de Entrada:G1/2

Porta de Saída:G1/2

Tamanho da Porta:G1/2

Marca:BXHS

Tipo de produto:Válvula Direcional Monobloco

Série de produtos:Série P40 Válvula Direcional Monobloco

Tamanho da embalagem:23*16*11

Peso bruto:3.00 kg

Disponibilidade: Em estoque

1196 Visualizações estão procurando por este produto

P40-G12-1OT Hydraulic Directional Valve | Manufacturer & Global Supplier

P40-G12-1OT Hydraulic Directional Valve | Manufacturer & Global Supplier

P40-G12-1OT Hydraulic Directional Valve | Manufacturer & Global Supplier drawing image

The Lkf Flow Valve P40-G12-1OT is a high-performance hydraulic directional valve designed for use in a wide range of applications, including construction equipment, material handling, industrial vehicles, and agriculture. This manual control monoblock valve features a rated flow of 40 L/min and a maximum pressure of 250 bar, making it suitable for demanding applications. It is also compatible with a variety of equipment, including telehandlers, forklifts, all-terrain cranes, and more.

Série P40 Válvula Direcional Monobloco Parâmetros
Método de Controle Manual, Pneumático, Eletropneumático, Eletrohidráulico, Solenoide, Hidráulico, Hidráulico e Manual, Cabo, Joystick, Solenoide e Joystick, Manual e Joystick, Solenoide e cabo
Carrétel 1 Carretel, 2 Carreteis, 3 Carreteis, 4 Carreteis, 5 Carreteis, 6 Carreteis, 7 Carreteis
Intervalo de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estrutura Válvula monobloco
Secção 1 secção, 2 secções, 3 secções, 4 secções, 5 secções, 6 secções, 7 secções
Intervalo de viscosidade operacional 15 - 75 mm²/s (15 cSt a 75 cSt)
Fluxo Nominal 40 L/min (10,5 US gpm)
Pressão Máxima 250 bar (3600 psi)
Porta de Entrada G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Porta de Saída G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Tamanho da Porta G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The Lkf Flow Valve P40-G12-1OT is a reliable and durable hydraulic directional valve designed for heavy-duty applications. It features a robust monoblock construction and a single spool, providing a compact and efficient design. The valve is equipped with a manual control system for easy operation and offers a rated flow of 40 L/min (10.5 US gpm) with a maximum pressure of 250 bar (3600 psi). It is suitable for operating viscosities ranging from 15 to 75 mm²/s (15 cSt to 75 cSt) and can withstand ambient temperatures from -40°C to +80°C (-40°F to +176°F). The valve is specifically designed for use in construction equipment, material handling, industrial vehicles, and agriculture. It is compatible with a wide range of applications and equipment models, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. This versatile and reliable hydraulic valve offers superior performance and durability, making it an ideal choice for a wide range of demanding applications.
