P40-G12-G38-OT Manual Hydraulic Directional Valve | Proven Performance

Método de Controle:Manual

Carrétel:2 Carreteis

Fluxo Nominal:40 L/min (10,5 US gpm)

Pressão Máxima:250 bar (3600 psi)

Porta de Entrada:G1/2

Porta de Saída:G1/2

Tamanho da Porta:G3/8

Marca:BXHS

Tipo de produto:Válvula Direcional Monobloco

Série de produtos:Série P40 Válvula Direcional Monobloco

Tamanho da embalagem:23*18*13

Peso bruto:5.50 kg

Disponibilidade: Em estoque

923 Visualizações estão procurando por este produto

P40-G12-G38-OT Manual Hydraulic Directional Valve | Proven Performance

P40-G12-G38-OT Manual Hydraulic Directional Valve | Proven Performance

P40-G12-G38-OT Manual Hydraulic Directional Valve | Proven Performance drawing image

This high-performance manual hydraulic directional valve from the P40 series is designed for demanding applications in material handling, construction, agriculture, and industrial vehicles. With a rated flow of 40 L/min and a maximum pressure of 250 bar, this robust monoblock valve offers proven reliability and efficiency.

Série P40 Válvula Direcional Monobloco Parâmetros
Método de Controle Manual, Pneumático, Eletropneumático, Eletrohidráulico, Solenoide, Hidráulico, Hidráulico e Manual, Cabo, Joystick, Solenoide e Joystick, Manual e Joystick, Solenoide e cabo
Carrétel 1 Carretel, 2 Carreteis, 3 Carreteis, 4 Carreteis, 5 Carreteis, 6 Carreteis, 7 Carreteis
Intervalo de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estrutura Válvula monobloco
Secção 1 secção, 2 secções, 3 secções, 4 secções, 5 secções, 6 secções, 7 secções
Intervalo de viscosidade operacional 15 - 75 mm²/s (15 cSt a 75 cSt)
Fluxo Nominal 40 L/min (10,5 US gpm)
Pressão Máxima 250 bar (3600 psi)
Porta de Entrada G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Porta de Saída G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Tamanho da Porta G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-G12-G38-OT manual hydraulic directional valve is a two-section, monoblock valve with a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure of 250 bar (3600 psi). This valve features a robust design with two spools and operates with a viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt). It is suitable for use in a wide range of temperatures, from -40°C to +80°C (-40°F to +176°F). Designed for demanding applications in material handling, construction and earth moving, agriculture, and industrial vehicles, this valve is compatible with a variety of equipment, including telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, and skid steer loaders. Its proven performance and durability make it a reliable choice for a variety of applications.
