P80-AQF-G Series Monoblock Directional Valve: Wholesale & OEM

Método de Controle:Manual

Carrétel:6 Carreteis

Fluxo Nominal:80 L/min (21,2 US gpm)

Pressão Máxima:250 bar (3600 psi)

Porta de Entrada:G3/4

Porta de Saída:G3/4

Tamanho da Porta:G1/2

Marca:BXHS

Tipo de produto:Válvula Direcional Monobloco

Série de produtos:Série P80 Válvula Direcional Monobloco

Tamanho da embalagem:26*36*11

Peso bruto:18.60 kg

Disponibilidade: Em estoque

1053 Visualizações estão procurando por este produto

P80-AQF-G Series Monoblock Directional Valve: Wholesale & OEM

P80-AQF-G Series Monoblock Directional Valve: Wholesale & OEM

P80-AQF-G Series Monoblock Directional Valve: Wholesale & OEM drawing image

The P80-AQF-G Series Monoblock Directional Valve is a high-performance hydraulic control valve designed for a wide range of applications, including material handling, construction, earthmoving, agriculture, and industrial vehicles. This 6-section valve features a rated flow of 80 L/min and a maximum pressure rating of 250 bar, making it ideal for demanding applications.

Série P80 Válvula Direcional Monobloco Parâmetros
Método de Controle Manual, Pneumático, Eletropneumático, Eletrohidráulico, Solenoide, Hidráulico, Hidráulico e Manual, Cabo, Joystick, Manual e Joystick
Carrétel 1 Carretel, 2 Carreteis, 3 Carreteis, 4 Carreteis, 5 Carreteis, 6 Carreteis, 7 Carreteis
Intervalo de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estrutura Válvula monobloco
Secção 1 secção, 2 secções, 3 secções, 4 secções, 5 secções, 6 secções, 7 secções
Intervalo de viscosidade operacional 15 - 75 mm²/s (15 cSt a 75 cSt)
Fluxo Nominal 80 L/min (21,2 US gpm)
Pressão Máxima 315 bar (4600 psi)
Porta de Entrada G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Porta de Saída G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Tamanho da Porta G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

This Three Way Hydraulic Control Valve, part of the P80-AQF-G series, is a robust monoblock directional valve designed for demanding applications in industries such as material handling, construction, and earthmoving. This 6-section valve boasts a rated flow of 80 L/min and a maximum pressure rating of 250 bar, ensuring high performance and reliability. Its manual control method offers user-friendly operation. With a wide operating viscosity range of 15 to 75 mm²/s and an ambient temperature range of -40°C to +80°C, this valve is suitable for diverse operating environments. Its 6-spool design provides versatility and control for various hydraulic circuits. This valve is perfect for a wide range of machinery, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. We offer wholesale and OEM options for this valve, catering to diverse needs. Contact us for more details and customized solutions.
