The P80-G34-OT Manual 7 Spool Monoblock Directional Valve is a high-performance hydraulic control solution designed for demanding applications in various industries. With a rated flow of 80 L/min and a maximum pressure of 250 bar, it provides exceptional flow capacity and pressure handling capabilities.
| Série P80 Válvula Direcional Monobloco Parâmetros | |
|---|---|
| Método de Controle | Manual, Pneumático, Eletropneumático, Eletrohidráulico, Solenoide, Hidráulico, Hidráulico e Manual, Cabo, Joystick, Manual e Joystick |
| Carrétel | 1 Carretel, 2 Carreteis, 3 Carreteis, 4 Carreteis, 5 Carreteis, 6 Carreteis, 7 Carreteis |
| Intervalo de temperatura ambiente | -40 °C a +80 °C (-40 °F a +176 °F) |
| Tipo de estrutura | Válvula monobloco |
| Secção | 1 secção, 2 secções, 3 secções, 4 secções, 5 secções, 6 secções, 7 secções |
| Intervalo de viscosidade operacional | 15 - 75 mm²/s (15 cSt a 75 cSt) |
| Fluxo Nominal | 80 L/min (21,2 US gpm) |
| Pressão Máxima | 315 bar (4600 psi) |
| Porta de Entrada | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Porta de Saída | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Tamanho da Porta | G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT |
**P80-G34-OT Manual 7 Spool Monoblock Directional Valve**
The P80-G34-OT Manual 7 Spool Monoblock Directional Valve is a robust and reliable hydraulic control component engineered for precision and efficiency. Key features and specifications include:
* **Manual Control:** Allows for precise and responsive operation of the valve.
* **7 Spool Design:** Provides versatile flow control with multiple spool configurations.
* **Monoblock Construction:** Offers a compact and integrated design for space optimization.
* **High Flow Capacity:** Rated flow of 80 L/min ensures efficient fluid transfer.
* **Exceptional Pressure Handling:** Maximum pressure of 250 bar enables operation in high-pressure hydraulic systems.
* **Wide Viscosity Range:** Suitable for applications with operating viscosities ranging from 15 to 75 mm²/s.
* **Durable Construction:** Manufactured with high-quality materials and components for extended service life.
* **Versatile Applications:** Ideal for demanding hydraulic systems in industries such as material handling, construction, agriculture, and industrial vehicles.
