Q45 Solenoid and Manual 1 Spool Monoblock Directional Valve for Hydraulic Systems

Método de Controle:Eletroímã manual e de tração-compressão (push-pull)

Carrétel:1 Carretel

Fluxo Nominal:45 L/min (11,8 US gpm)

Pressão Máxima:315 bar (4600 psi)

Porta de Entrada:G1/2

Porta de Saída:G1/2

Tamanho da Porta:G1/2

Marca:BXHS

Tipo de produto:Válvula Direcional Monobloco

Série de produtos:Série Q45 Válvula Direcional Monobloco

Tamanho da embalagem:28* 18*16

Peso bruto:8.00 kg

Disponibilidade: Em estoque

63 Visualizações estão procurando por este produto

Q45 Solenoid and Manual 1 Spool Monoblock Directional Valve for Hydraulic Systems

Q45 Solenoid and Manual 1 Spool Monoblock Directional Valve for Hydraulic Systems

Q45 Solenoid and Manual 1 Spool Monoblock Directional Valve for Hydraulic Systems drawing image

The Q45 Series is a versatile 1-spool monoblock directional control valve designed for hydraulic systems requiring dual solenoid and manual control. With a rated flow of 45 L/min and a maximum pressure rating of 315 bar, this high-performance valve is engineered for durability and precision across material handling, construction, and agricultural machinery.

Série Q45 Válvula Direcional Monobloco Parâmetros
Método de Controle Manual, Pneumático, Eletropneumático, Eletrohidráulico, Solenoide, Joystick, Solenóide e Manual, Eletroímã manual e de tração-compressão (push-pull), Eletroímã de tração-compressão (push-pull)
Carrétel 1 Carretel, 2 Carreteis, 3 Carreteis, 4 Carreteis, 5 Carreteis, 6 Carreteis, 7 Carreteis
Intervalo de temperatura ambiente -20°C a +80°C (-4°F a +176°F)
Tipo de estrutura Válvula monobloco
Secção 1 secção, 2 secções, 3 secções, 4 secções, 5 secções, 6 secções, 7 secções
Intervalo de viscosidade operacional 15 - 75 mm²/s (15 cSt a 75 cSt)
Fluxo Nominal 45 L/min (11,8 US gpm)
Pressão Máxima 315 bar (4600 psi)
Porta de Entrada G1/2
Porta de Saída G1/2
Tamanho da Porta G1/2

As a leading manufacturer of premium hydraulic components, we proudly present the Q45 Series Solenoid and Manual 1 Spool Monoblock Directional Valve. This robust valve offers exceptional control for various applications including forklifts, tractors, mini-excavators, and aerial platforms. Featuring G1/2 inlet and outlet ports, it supports a flow capacity of 45 L/min (11.8 US gpm) and operates effectively up to 315 bar (4600 psi). We provide comprehensive manufacturing services, including professional OEM and ODM solutions, private labeling (branding), and bespoke customization to meet specific technical requirements. Our factory is fully equipped for large-scale production, offering competitive wholesale pricing and reliable supply chains. We are actively seeking global partners, including distributors, wholesalers, regional agents, and international traders to expand our market reach. Whether you need a trusted factory supplier for bulk orders or a partner for specialized hydraulic valve development, our team provides the technical expertise and manufacturing excellence required for long-term success in the hydraulic industry.
