SDS180Q 3 Spool Sectional Directional Valve supports manual/pneumatic control with 160 L/min flow and 315 bar max pressure. Manufactured by a 25-year IATF 16949 certified factory, it ensures reliability for mini-excavators and loaders.
| Série SDS180 Válvula direcional seccional Parâmetros | |
|---|---|
| Método de Controle | Manual, Hidráulico, Pneumático e Manual |
| Carrétel | 1 Carretel, 2 Carreteis, 3 Carreteis, 4 Carreteis, 5 Carreteis, 6 Carreteis, 7 Carreteis |
| Intervalo de temperatura ambiente | -40 °C a +80 °C (-40 °F a +176 °F) |
| Tipo de estrutura | Válvula seccional |
| Secção | 1 secção, 2 secções, 3 secções, 4 secções, 5 secções, 6 secções, 7 secções, 8 secções, 9 secções, 10 secções |
| Intervalo de viscosidade operacional | 12 - 400 mm²/s (12 cSt a 400 cSt) |
| Fluxo Nominal | 160 L/min (42,2 US gpm) |
| Pressão Máxima | 315 bar (4600 psi), 350 bar (5100 psi) |
| Porta de Entrada | G3/4, G1, SAE 12 |
| Porta de Saída | G1, SAE 16 |
| Tamanho da Porta | G3/4, G1, SAE 12 |
**1. High-Flow Sectional Directional Valve Specs**
- Rated for 160 L/min (42.2 US gpm) flow and 315 bar (4600 psi) max pressure, ensuring efficient power transmission.
- Features G3/4 inlet and G1 outlet ports, optimized for compact hydraulic circuits in heavy-duty applications.
**2. Versatile Hydraulic Directional Control Valve Operation**
- Dual control method: Manual lever and Pneumatic operation provide flexible integration for automated or manual systems.
- 3 Spool design allows independent control of multiple actuators, ideal for complex machinery like telehandlers and backhoes.
**3. Reliable Pneumatic Operated Hydraulic Valve Quality**
- Produced in a 68,000 sqm facility with 260+ CNC machines; every unit undergoes 100% pressure and leakage testing.
- Certified under IATF 16949 and CE standards, guaranteeing consistent performance and durability in harsh environments.
**4. Customizable 3 Spool Hydraulic Valve Solutions**
- OEM/ODM Available: Support for private label, custom logo laser marking, and specific port configurations to match your brand.
- Backed by 35+ senior engineers with 10+ years of experience, offering tailored solutions for unique vehicle requirements.
**5. Factory Direct Sales & Global Compatibility**
- Wholesale China Factory direct supply eliminates middlemen, offering competitive pricing for distributors and wholesalers.
- Perfectly compatible with major international brands, serving mini-excavators, skid steers, and agricultural tractors worldwide.
