Your Hydraulic Partner: OEM, ODM, and White Label Services for P40-G12-1OT

Método de Controle:Manual

Carrétel:1 Carretel

Fluxo Nominal:40 L/min (10,5 US gpm)

Pressão Máxima:250 bar (3600 psi)

Porta de Entrada:G1/2

Porta de Saída:G1/2

Tamanho da Porta:G1/2

Marca:BXHS

Tipo de produto:Válvula Direcional Monobloco

Série de produtos:Série P40 Válvula Direcional Monobloco

Tamanho da embalagem:23*16*11

Peso bruto:3.00 kg

Disponibilidade: Em estoque

1032 Visualizações estão procurando por este produto

Your Hydraulic Partner: OEM, ODM, and White Label Services for P40-G12-1OT

Your Hydraulic Partner: OEM, ODM, and White Label Services for P40-G12-1OT

Your Hydraulic Partner: OEM, ODM, and White Label Services for P40-G12-1OT drawing image

Introducing Your Hydraulic Partner: a leading provider of OEM, ODM, and White Label services for hydraulic products. Our expertise lies in developing and manufacturing high-quality hydraulic components and systems tailored to meet your specific needs. Partner with us to elevate your product offerings with our exceptional manufacturing capabilities and commitment to innovation.

Série P40 Válvula Direcional Monobloco Parâmetros
Método de Controle Manual, Pneumático, Eletropneumático, Eletrohidráulico, Solenoide, Hidráulico, Hidráulico e Manual, Cabo, Joystick, Solenoide e Joystick, Manual e Joystick, Solenoide e cabo
Carrétel 1 Carretel, 2 Carreteis, 3 Carreteis, 4 Carreteis, 5 Carreteis, 6 Carreteis, 7 Carreteis
Intervalo de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estrutura Válvula monobloco
Secção 1 secção, 2 secções, 3 secções, 4 secções, 5 secções, 6 secções, 7 secções
Intervalo de viscosidade operacional 15 - 75 mm²/s (15 cSt a 75 cSt)
Fluxo Nominal 40 L/min (10,5 US gpm)
Pressão Máxima 250 bar (3600 psi)
Porta de Entrada G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Porta de Saída G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Tamanho da Porta G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

Our P40-G12-1OT monoblock valve is a prime example of our engineering prowess. Designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles, this valve delivers exceptional performance with a rated flow of 40 L/min, a maximum pressure of 250 bar, and an operating viscosity range of 15 - 75 mm²/s. Its robust construction ensures reliable operation in harsh environments with an ambient temperature range of -40°C to +80°C. Whether you require OEM manufacturing, ODM customization, or White Label branding, we have the expertise and infrastructure to fulfill your requirements. Our commitment to quality and customer satisfaction sets us apart, making us the ideal choice for businesses seeking a reliable hydraulic partner.
